This is the January 1978 Standard and Kit Boat Specification
(appears to be Mk2)
Complete Boat
- Kit Boat
TRAPPER 300
|
The Trapper 300 was designed as a fast
cruising yacht by Bruce Kirby of ‘Laser’ fame. To date over 100 have
been built and can be seen sailing, not only in Europe, but also in Hong
Kong, the U.S.A. and even behind the Iron Curtain.
Her fine lines attract the yachtsman who
appreciates the best in modern design for she is without doubt a beautiful
yacht, yet her sleek looks belie her spacious accommodation, with standing
headroom for most people.
|
HULL |
The hull and deck mouldings are constructed
of glass reinforced polyester, hand laid by our Moulding Division and
consist of woven rovings and chopped fibre-glass mat incorporating high
grade marine polyester resin calculated to give the best strength/weight
ratio. The standard colour is white, but a coloured stripe can be moulded
in as an extra. The underwater surfaces are painted with a high quality
anti-fouling.
|
DECK
AND
COACHROOF |
The deck and coachroof is reinforced with
balsa core and plywood stiffening, and incorporates a moulded non-slip
finish, a bow anchor well and deep cockpit locker for sails or dinghy.
Other features include gas bottle stowage with drain, self draining
cockpit and translucent flush fitting forehatch.
|
KEEL
(Fin) |
2028 lbs. (920 kgs.) cast iron through
bolted to the hull with 20 mm diameter stainless steel (SIS) studs
and plates. A special lead keel can be supplied as an extra.
|
RUDDER |
The spade rudder gives excellent
directional control under sail or power. The stock is 35 mm sold S/S bar
encapsulated inside the strongly constructed GRP blade. The tiller head
fitting, bearings and collar are heavy S/S and bronze castings for
confidence in severe weather.
|
INTERIOR |
The accommodation is based on two
fibreglass modules which are bonded to the hull for massive strength. A
headliner forming a double skin is fitted throughout to resist
condensation and noise.
The forward cabin has a double berth with
stowage beneath and shelves port and starboard. The heads area can be
completely enclosed with the marine toilet and wet hanging locker to
starboard, dry hanging locker to port.
The saloon has a dinette to starboard with
ample deep bins and lockers for stowage.
To port, the galley includes a deep sink,
gimballed gas cooker with grill, extensive working surfaces, cupboards,
cutlery drawer and large lockers, including a waste disposal bin. A deck
mounted flexible ventilator is installed overhead. An ice box is located
under the quarter berth.
The navigator enjoys a permanent chart
table which includes chart stowage below, and ample space for instrument
mounting and navigation equipment.
|
SLEEPING
ACCOMMODATION |
Sleeps five people comfortably, two in the
forecabin, a double in the main saloon and a quarter berth. All berths
have 3" deep foam cushions covered with synthetic water resistant
fabric.
|
FINISH |
All interior and exterior teak surfaces are
lightly oiled to a matt silky finish. The hardwood tiller is varnished.
|
DECK
EQUIPMENT |
Anodised aluminium toerail. S/S pushpit and
pulpit. Aluminium stemhead fitting incorporating bow roller. Aluminium
stanchions, mooring cleats and fairleads. Mainsheet track, slider and
stops. Two Lewmar 16a two speed sheet winches with cleats, two Lewmar 6a
halyard winches with cleats. Alloy genoa tracks and sliders. Winch handle.
Bilge pump and handle.
|
MAST
AND
RIGGING |
Anodised aluminium mast with streamlined
spreaders, spinnaker pole track and pole fitting. Anodised aluminium boom
with hooks and clam cleats for slab reefing. 5 mm 1 x 19 S/S wire rigging
with swaged terminals. Main and genoa halyards of S/S wire with terylene
tails, terylene genoa and main sheets and burgee halyard.
|
ELECTRICS |
55 amp. hr. 12v Battery. Fused switch panel
and battery isolating switch. Six interior lights. Bi-colour port and
starboard and stern light to international standards. Steaming light
standard with engine installation.
|
PLUMBING |
All underwater hull fittings are approved
bronze seacocks with S/S hose clips. 20 gallon (90 litres) double skinned
flexible water tank with deck filler. Fresh water flipper pump in galley.
|
ENGINE
(Optional extra) |
Yanmar
YSE 8 lightweight (125 kgs.) diesel with reverse and 2 to 1 reduction
gear. Fitted on flexible mountings with alternator, electric and hand
start. Permanent oil drip tray. Remote control panel with twin lever
controls. Bronze two bladed propellor (folding optional). 4 gallon (18
litres) vented fuel tank with deck filler. |
GROUND
TACKLE
AND MOORINGS |
20 lb. COR anchor, 2 fathoms galvanised
chain, 12 mm terylene anchor warp, 2 x 12 mm mooring warps. 3 fenders with
tails.
|
SAILS |
Mainsail, 111 sq. ft. in 8 oz. Terylene
with battens, 2 rows of reef points, sailbag. Working jib, 112 sq. ft. in
8 oz. Terylene with hanks and sailbag.
|
PRICE |
Price includes design Royalty fee.
|
SPECIFICATION
CHANGES |
Trapper Yachts reserve the right to alter
this specification either through design improvements or material
shortages beyond their control but undertake to supply fittings of a
similar nature.
|
TERMS |
Subject to Ship and Boat Builders’
National Federation Contract. 10% Deposit with contract. Balance 7 days
prior to collection.
|
PRICE |
Trapper 300 excluding engine £ 7475
Ex works Poole.
Yanmar diesel fitted £ 1675
|
|
Note: LAUNCHING
OR LOADING EXTRA.
All prices exclusive of VAT. |
|
The Kit is supplied in an advanced stage of
construction. The interior accommodation and headliner mouldings. main
bulkhead and mast post are bonded in, and the deck is completely fitted to
the hull, including aluminium toerail and rubbing strake. The keel is
fitted. Windows and forehatch are cut out and the interior mouldings
trimmed ready for fitting out
N.B. With the windows, mainhatch, forehatch, cockpit locker, and
anchor well lid correctly fitted your 300 is a seaworthy yacht
|
SUPPLIED FITTED
|
Anodised
aluminium stemhead fitting incorporating chain roller and forestay
tang.
S/S
Backstay tang.
S/S
Chainplates.
Rudder
complete with delrin bearing and S/S collar.
P.V.C.
Buffer.
Anodised
toerail.
Electrical
wiring for interior and navigation lights.
2
x ½", Bronze seacocks for cockpit drains.
6
Stanchion bases.
Mast
step
S/S Pushpit
and S/S pulpit.
½"
Bronze sink drain seacock.
2 x Bronze
toilet seacocks.
Gas drain
skin fitting and hoses. |
SUPPLIED UNFITTED
|
Fibreglass
sliding mainhatch.
Alloy
runners and fastenings.
Finishing
strips for headlining interior moulding joint.
Fibreglass
forehatch, hinges and fastenings, lock and stay.
Fibreglass
backrest radius.
Fibreglass
anchor well lid, hinges and fastenings.
Anodised
aluminium mast, spreaders and spinnaker pole track and slider.
Aluminium
main boom, hooks and clam cleats.
Standing
rigging in 5 mm 1 x 19 S/S wire, terminals and rigging screws
Main sheet,
main and genoa halyards, genoa sheets, and burgee halyard
Hardwood
tiller (unvarnished) and tiller head fitting.
Tinted ‘perspex
windows, fastenings and GRP inserts. |
ROYALTY
|
Price
includes Royalty fee. |
FINANCE
|
Marine
mortgages are usually available and we shall be pleased to make
recommendations.
|
SPECIFICATION CHANGES |
Trapper Yachts reserve the right to alter this specification either
through design improvements or material shortages beyond their control but
undertake to supply fittings of a similar nature
|
TERMS
|
Subject to Ship and Boat Builders’ National Federation Contract 10%
Deposit with contract. Balance 7 days prior to collection.
|
PRICE |
£5195 Ex works Poole |
|
Note: LAUNCHING OR LOADING EXTRA
Price exclusive of V.A.T. |
|
7 Cabot Lane, Creekmoor Poole, Dorset, England
Tel (0202) 697551/2/3 Telex 377661 |
